ONAIR, 4 KW FM Amplifier

ONAIR, 4 KW FM Amplifier
ONAIR, 4 KW FM Amplifier

  •  It is designed using a very rugged LDMOS transistor. So, its efficiency is very high.
  • Max. Input power is 30W.
  • It has reflection, current and temperature protections.
  • Output power can be set to lower powers.
  • It has a room temperature and humidity sensor inside, so it automatically runs airconditioner according to transmitter room air condition.
  • It keeps event logs.
  • It has a remote control via an ethernet or 3G/4G USB stick.
  • N+1 redundancy system is ready to use.



 Very Efficient LDMOS Amplifier

 Our amplifiers are manufactured using high efficient LDMOS transistors.



 N+1 Redundancy system

 With the Built-in N+1 Redundancy system, you’ll be always on the air.



 Remote controlling has defaulted on FA’s!

 FA series has a built-in remote control system, which is also cloud-ready.

FM Transmitters
RF Power Stage Technology LDMOS
Amplifier Type Rack Type FM Amplifier
FM Amplifiers
Output Power 4000 W
Redundancy System Built in N+1 redundancy system.
Remote Control TCP/IP - internet- SNMP and cloud. Internet connection can be made via ethernet or USB. Cellular internet connection supported using 3G/4G USB stick.

Write a review

Please login or register to review
  • Stock: 20
  • Model: FA4K
  • Weight: 53.00kg
  • Dimensions: 775.00mm x 485.00mm x 220.00mm
